Philips HeartStart XL+ - Rear Side; Top Side

Tour of the Device 1: Introduction
5
Rear Side
Top Side
Figure 4 Rear Side View
Figure 5 Top Side View
LAN
ECG
50 - 60 Hz
100 - 240 V
1- 0.46 A
ECG
Out
Battery
compartment
Battery
AC Mains
LAN Port
(factory use only)
Battery
latch
RFU indicator
Therapy
Port
USB Port
Paddle Tray
(optional)
