Philips HeartStart XL+ - External Assemblies

4: Repair External Assemblies
72
External Assemblies
This section describes how to remove and replace assemblies that are external to the case. You do not need
to open the case for any of these procedures.
CAUTION: There are electrical components in the Handle Assembly. Wear ESD protection and follow electrical
safety precautions during the Handle and RFU-and-USB assemblies replacement.
NOTE: See the HeartStart XL+ Instructions for Use for information on attaching the carrying case and accessory
pouches.
This section is organized into the following topics:
 Battery Compartment Cover and Latch . . . . . . . . . . . . . p. 73
 Bedrail / Roll Stand Mount . . . . . . . . . . . . . . . . p. 74
 Labels . . . . . . . . . . . . . . . . . . . . p. 75
 Handle Assembly . . . . . . . . . . . . . . . . . . p. 78
 RFU-and-USB PCA . . . . . . . . . . . . . . . . . p. 80
 Paddle Tray and Plates . . . . . . . . . . . . . . . . . p. 81
 Paddle Tray, Blank . . . . . . . . . . . . . . . . . . p. 83
 Paddle Tray Load Resistor . . . . . . . . . . . . . . . . p. 84
 Printer Assembly . . . . . . . . . . . . . . . . . . p. 85
 Therapy Knob . . . . . . . . . . . . . . . . . . p. 86
