3: Troubleshooting Operational Check
38
Operational Check Completion
At completion of the Op Check:
• The message
Operational Check Passedis displayed if all of the tests pass.
• If any test fails, the message Operational Check Failed
is displayed along with one or more of the
following messages, depending upon the nature of the failed functionality:
• Service Device
• Replace Battery
• Replace Pads Cable
• Replace Paddles Cable
• Replace Therapy Cable
• Replace ECG Cable
Fix the problem and successfully run the Operational Check to clear the failure.
Operational Check Report
At the end of an Op Check, depending on the AutoPrint configuration setting, either the Op Check
report is printed, or Print Op Check Report to Check Printer prompt is displayed.
To export to a USB flash drive or print a copy of the report:
Select Exportor Print from the Main Menu.
You may export or print any number of copies while in the Op Check mode. After you exit Op Check,
the Op Check report is no longer available, but you still may find the result of the Op Check in the
Op Check summary (see “Operational Check Summary” on page 39).
Figure 26 shows a sample Op Check report. The first part of the report lists test results. The second part
lists checks to be performed by the user.
Figure 26 Operational Check Report
Operational Check Report Current Test Results:
General System Test: Pass Battery Test: Pass
HeartStart XL+ 861290 Therapy Knob: Pass SpO2 Test: Pass
S/N: US00123456 Charge Button: Pass EtCO2 Test: Pass
Sw Rev: B.00.00 American English Shock Button: Pass NBP Test: Pass
Audio Test: Pass Printer Test: Pass
Current Operational Check : Sync Button: Pass
31 May 2013 12:34 Pass Therapy Delivery Test: Pass/Pads
Leads ECG Test: Pass/ECG Cable
Last Operational Check : Pads/Paddles ECG Test: Pass/Pads
29 May 2013 01:23 Pass
Qty/Check List : Comments:
Inspected By:__________________
___ Defibrillator Inspection ___ NBP Cuff(s) & Tubing
___ ECG Cables/Connectors ___ USB Connector
___ Paddles/Pads
___ Monitoring Electrodes
___ Charged Battery
___ AC Power Cord
___ Printer Paper
___ SpO2 Sensor
___ EtCO2 Sensor
___ EtCO2 Sampling Line
