4: Repair Internal Assemblies — Front Chassis
138
6 Replace the Printer PCA, the Therapy Port Extension assembly, and the Printer ribbon cable. See
“Printer PCA” on page 124.
7 Ensure the connectors are fully seated.
8 If present, replace the SpO
2
PCA. See “SpO2 PCA” on page 126.
9 Close the device. See “Closing the Case” on page 151.
Entering the Serial Number
After you have replaced the Processor PCA and reassembled the device, you must enter the device’s serial
number to make the HeartStart XL+ operational. If the serial number is not entered, the device powers
up with the message Equipment Disabled: Therapy. Normal operation is not possible, and the device
powers up into Service Mode, where you can enter the serial number.
 To enter the serial number:
1 Tu r n th e de vi c e o ff .
2 Record the model number, serial number, and options key(s) from the bottom of the device.
3 Insert AC power and a battery (charged to at least 20%) and turn the Therapy Knob to Monitor.
The device powers up into Service Mode.
4 From the Service Mode Main menu, select Device Info.
5 From the Device Info menu, select Serial Number. An alphanumeric menu is displayed, see
Figure 93.
6 Enter the serial number using the Navigation buttons to scroll through the letters and numbers.
Press the Menu Select button to complete each selection.
Select Cancel or Backspace to cancel a selection.
Figure 93 Entering Serial Number


 
 
 
 











