Components Troubleshooting
The Troubleshooting tables provide information on messages and common troubleshooting issues.
NOTE: Before replacing any components, always run an Operational Check and check the Error Logs for
messages. Before replacing any parts, check to see if all the cables and flex circuits are properly connected
See “Repair Notes” on page 96.
If several solutions are offered for your problem, always try the solutions in the order they are listed, and
apply the next solution only if the previous solutions did not fix the problem.
This section is organized into the following subsections:
 Power and Battery . . . . . . . . . . . . . . . . . . p. 46
 Audio Tones . . . . . . . . . . . . . . . . . . . p. 50
 Startup Messages . . . . . . . . . . . . . . . . . . p. 51
 General Problems . . . . . . . . . . . . . . . . . . p. 52
 Pacing Problems . . . . . . . . . . . . . . . . . . p. 53
 ECG Monitoring Problems . . . . . . . . . . . . . . . . p. 54
 Defibrillation Problems . . . . . . . . . . . . . . . . p. 56
 SpO2 Monitoring Problems . . . . . . . . . . . . . . . p. 59
 CO2 Monitoring Problems . . . . . . . . . . . . . . . . p. 60
 NBP Monitoring Problems . . . . . . . . . . . . . . . . p. 61
 Controls Problems . . . . . . . . . . . . . . . . . . p. 62
 USB Problems . . . . . . . . . . . . . . . . . . p. 63
 Display Problems . . . . . . . . . . . . . . . . . . p. 63
 Printing Problems . . . . . . . . . . . . . . . . . . p. 64
 Audio Problems . . . . . . . . . . . . . . . . . . p. 65
Power and Battery
The HeartStart XL+ lithium-ion battery provides the power necessary to operate your HeartStart XL+
monitor/defibrillator. Proper battery maintenance described in the “Battery Maintenance” section of
HeartStart XL+ Instructions for Use and HeartStart XL+ Lithium-Ion Battery Characteristics and Care
Application Note ensures your HeartStart XL+’s readiness and uninterrupted power supply.
Faulty Batteries
CAUTION: A HeartStart XL+ battery that cannot pass calibration is a faulty battery and cannot serve as a reliable
power source for the HeartStart XL+’s clinical purposes. A battery that can deliver power may still be
faulty. Do not use faulty batteries for any purposes.
If a faulty battery is connected to the device along with AC power source, the faulty battery may not be
revealed until the device attempts and fails to draw power from the battery.
Recycle or discard faulty batteries according to local regulations.
