1: Introduction Device Information
10
Device Information
You can print detailed information on software versions, board and module levels, and internal memory
card capacity from the Print Device Info menu option.
To print the device information:
1 Make sure a battery charged to at least 20% is in place, or that external power is connected.
2 Tu r n th e Th er a py Kn o b t o Monitor.
3 Press the Menu Select button to access the Main menu.
4 From the Main menu, select Other.
5 From the Other menu, select Print Device Info.
Detailed information about the device is printed.
NOTE: Run an Operational Check after you have updated software, enabled an option, or performed a repair to
update the device information.
Primary Label
TheHeartStart XL+ ships with a primary label shown in Figure 7 affixed to the bottom of the Rear Case.
Other Resources
For additional information on the HeartStart XL+, refer to the following Learning Products:
• HeartStart XL+ Instructions for Use
•HeartStartXL+ Service Web-based Training
•HeartStartXL+ Lithium-Ion Battery Characteristics and Care Application Note
Other documents can be found on the Philips website at:
http://www.philips.com/ProductDocs.
Figure 7 Primary Label Fragment
Service #
861290
SN
USmyynnnnn
REF 861290
OPT Options List
OPT KEY Options Key
UDI Unique Device Identifier
Options List:
List of options installed on the device
USmyynnnnn:
m – month of manufacturing code
yy – last two digits of the year of manufacturing
nnnnn – unique number
Options Key:
Key for options activation
