Philips HeartStart XL+ - Operational Check Setup

3: Troubleshooting Operational Check
34
NOTE: If testing paddles, make sure that they are secured in their pockets. If the patient contact indicator (PCI)
LEDs light, adjust the paddles in the pockets to improve the electrical contact. If the LEDs continue to
light, clean the paddle electrode surfaces.
Operational Check Setup
The HeartStart XL+ performs the readiness check, and when all readiness conditions are satisfied begins
to run Op Check tests.
Carefully read the setup instructions on the screen, see Figure 24 for a sample. Once the HeartStart XL+
is set up properly, you can proceed with the Op Check.
You cannot perform the Op Check without a sufficiently charged battery. If there is no battery in the
device then the prompt message Insert Charged Battery or Exit appears. If the battery charge is low,
then the prompt message Battery Charge Low, Replace Battery appears.
Options are tested only if present.
NOTE: If you choose to “proceed as is” without performing the required actions, the Op Check will fail. Press
the Menu Select button to proceed as is.
Figure 24 Operational Check Screen — Setup



















