5: Performance Verification Performance Verification Procedures
162
To r u n Op C he ck :
1 Insert a a sufficiently charged battery (at least two LEDs light up).
2 Access Service Mode (see “Accessing Service Mode” on page 8).
3 From the Service Mode Main menu, select Operational Check and press the Menu Select button.
NOTE: You can run Op Check from the Other menu in Monitor Mode or from the Service Mode Main menu
— the Op Check is the same in both modes.
4 When a response is required, use the Navigation buttons to select your answer and the Menu Select
button to confirm your choice.
See “Operational Check” on page 33 for more information on the Op Check procedure.
To check the Error Logs:
Select Hardware Error Log or Software Error Log from the Service Mode Main menu.
The Error logs includes entries for all messages logged during all operating modes, Automated tests,
Service tests, and Op Checks. See “Error Log Messages” on page 41 for more information.
Battery Test
See “Battery Maintenance” on page 16.
Controls Test
Run these tests when the controls performance becomes a suspect.
To perform controls test:
1 Access Service Mode
2 Select Controls Test from the Service Mode menu.
The controls test screen appears (Figure 105 on page 163).
3 Press all the indicated keys in turn and observe check marks appearing in the corresponding boxes.
If after pressing a key, the corresponding check mark does not appear, or appears in a wrong box,
note the malfunctioning key.
NOTE: Press the soft key #1 once to check the box and enable the Main Service function. If pressed again, soft
key #1 returns you to the Main Service screen.
4 Turn the Therapy Knob to every position and observe the screen designation changing accordingly.
5 If there is a mismatch, then:
• If there is a mismatch in Therapy Knob, then check the Therapy Knob connections and replace
the Therapy Knob or Therapy Switch as necessary.
• If there is a mismatch in the Paddles group, then check the Paddles connections and test the
Paddles.
• If there is a mismatch in the Charge/Shock/Sync buttons, then check the Human Interface PCA
connections and replace the Human Interface PCA if necessary.
• If there is a mismatch in other buttons or keys, then check the Front Case connections and
replace the Front Case if necessary.
If all results pass, the device passes that portion of the test. Return to the Service Mode Main screen by
pressing the Main Service soft key. If there is any failure, begin troubleshooting and repair the device as
needed.
