Supplies and Accessories A: Parts and Accessories
189
Key Components
Key Components require tracking, as indicated in Table 6 0. Record the part number and tracking
method (the date code, serial number, or lot/batch#) for both the failed and replacement components.
Table 60 Key Components
Replacement Assembly Kit or SPK Key Component
Description Part Number Description Part Number Tracking Method
Replacement PCAs
Processor PCA SPK 453564570771 Processor PCA 453564081201
Serial NumberTherapy PCA SPK 453564570781 Therapy PCA 453564081221
HIF PCA kit 453564206071 HIF PCA 453564206071
Electrical Assemblies
Display Assembly 453564206141
LED Display
Inverter PCA
453564105151
453564176811
Serial Number and
Date Code
Therapy Capacitor Assembly 453564206351 Therapy Capacitor 453564222111 Serial Number
Therapy Port SPK 453564570661 Therapy Port 453564570661 Date Code
Speaker Assembly 453564570731 Speaker 453564570731 Date Code
Therapy Switch Assembly 453564206301 Switch Encoder 453564128851 Serial Number
Lithium-Ion Battery 989803167281 Lithium-Ion Battery 453564088931 Serial Number
Power Supply 453564206121 Power Supply 453564088941 Date Code
Internal Resistors 453564258081 Internal Resistors 453564258081 Date Code
Ports and Cables
Therapy Port 453564206501 Therapy Receptacle 453564104981
Date Code
Pads Cable
M3507A
M3508A
barrel connector
plug connector
M3507-60007
M3508-60008
Supplies & Accessories
External Defibrillation Paddles
External Paddles
453564104911 External Paddles Assembly 453564104911 Date Code
M3543A External Paddles M3543A Serial Number
Internal Defibrillation Paddles
Internal Defibrillation
Paddles
M1741A
M1742A
M1743A
M1744A
7.5-cm Switchless
6.0-cm Switchless
4.5-cm Switchless
2.8-cm Switchless
M1741A
M1742A
M1743A
M1744A
Date Code
M4741A
M4742A
M4743A
M4744A
7.5-cm Switched
6.0-cm Switched
4.5-cm Switched
2.8-cm Switched
M4741A
M4742A
M4743A
M4744A
Tw o D at e Co d es :
paddles, connector
M4740A Adapter Cable M4740-61601 Date Code
