Out-Of-Hospital Transport - Standards Compliance 31 Installation and Specifications
303
• Specification for degrees of protection provided by enclosures according to IEC/EN 60529: IP 32
• EN 1789 +A1:2003 Medical vehicles and their equipment - Road ambulances (chapter 6 - Medical
Devices).
• Radiated susceptibility 20 V/m according to EN ISO 9919 (SpO
2
) and EN ISO 21647 (CO
2
).
• Altitude Range from -500 to 3000 m operating and -500 to 4600 m storage and transportation.
• Extended radiated susceptibility tests
The MP5 patient monitor with its out-of-hospital parameter set provides a general immunity level
of 20 V/m with only few restrictions. Details are as listed below:
– GSM 900: Immunity at 900 MHz (uplink mobile phone), 20 V/m (ECG:10 V/m), duty cycle
1:8
– GSM 1800: Immunity at 1800 MHz (uplink mobile phone), 20 V/m, duty cycle 1:8.
– DECT: Immunity at 1800 MHz (digital cordless phone), 20 V/m, duty cycle 1:24
– AM: 1 kHz Immunity from 80 MHz to 1.0 GHz (any radio communication unit, broadcasting
and TV transmitter), 20 V/m, modulation factor 80 %.
(ECG: 20 V/m except 600-950 MHz
where it is 10 V/m and Temperature which holds 3 V/m over the full range).
CAUTION Temperature measurement accuracy may be compromised in the presence of strong electromagnetic
fields (>3V/m) in certain small frequency bands.
• Magnetic Field emission according to MIL STD 461E, Chapter RE101: Radiated emissions,
magnetic field, 30 Hz to 100 kHz. Limit class: Army.
• Magnetic Field susceptibility: Radiated susceptibility, magnetic field, 50, 60 and 400 Hz,
18 µT(15 A/m)
• Operating ambient temperature testing over the range from 0 to 40°C (32 to 100°F).
• Operating ambient humidity testing up to 95 % RH at 40°C (100°F), non condensing.
NOTE There may be additional requirements for transport situations in air, on water or in difficult terrain in
certain countries, e.g. EU.
Physical Specifications
Specification Comments
Maximum Weight
4.0 kg ±5 %
(8.8 lb)
with ECG/Resp, NBP, SpO
2
and battery
W x H x D
<259 x 248 x 186 mm
10.2 x 9.8 x 7.3 in
without Predictive Temperature unit
<312 x 248 x 186 mm
12.3 x 9.8 x 7.3 in
with Predictive Temperature unit
