ECG, Arrhythmia, ST and QT Default Settings

ECG Settings

Factory defaults H10 / H20 / H40 H30 (deviations from H10/20/40)

Adult Pedi Neo Adult Pedi Neo

High Limit 120 bpm 160 bpm 200 bpm

Low Limit 50 bpm 75 bpm 100 bpm

Alarms On

Alarm Source Auto Auto

ECG On

QRS Volume 1

Primary Lead II

Secondary Lead V

Analysis Mode Multi-lead

Lead Placement Standard

Mod. Lead Placment Off

Filter Monitor Filter

Speed 25 mm/s

Auto Filter Off

Default ECG Size x1

Color Green

Asystole Thresh 4.0 sec 3.0 sec

ExtrTachy 20 bpm

Tachy Clamp 200 bpm 220 bpm 240 bpm

ExtrBrady 20 bpm

Brady Clamp 40 bpm 50 bpm 40 bpm 60 bpm 80 bpm

ECG AL. OFF Inop Cyan

Fallback On

Alarms Off Enabled

Alarm Source Sel. Enabled

Va Lead V2

Vb Lead V5

SyncPulse Sensit Medium

SyncPulse Marker On

PulseAlarms Tele Enabled
