ECG, Arrhythmia, ST and QT Default Settings 32 Default Settings Appendix

335

Arrhythmia Settings

Factory defaults H10 / H20 / H40 H30 (deviations from H10/20/40)

Adult Pedi Neo Adult Pedi Neo

Arrhythmia

On Off Off

Pause Threshold 2.0 sec 1.5 sec

VTach HR 100 120 150

VTach Run 5

Vent Rhythm 14

SVT HR 180 200 210

SVT Run 5

PVCs/min 10 5 5

Non-Sustain On

Vent Rhythm On

Run PVCs On

Pair PVCs On

Off

R-On-T PVCs On

Off

V. B i ge m i ny O n

Off

V. Tr i g e mi n y O n

Off

PVCs/min On

Off

Multif. PVCs On

Off

Pacer N. Cap On

Pacer N. Pac On

Pause On

Off

Missed Beat On

Off

SVT On

Afib On

IrregularHR On

Off

HR Alarms Short Yellow

TimeOut 1st 3 min

TimeOut 2nd 10 min

Arrhy Off Message Yes

SOME ECG... Inop On

Off

Lead-independent ST Settings Factory Adult Factory Pedi Factory Neo

ST Alarm Mode Single ST

Alarms On
