Alarm and Measurement Default Settings 32 Default Settings Appendix

333

Alarm and Measurement Default Settings

Settings are only entered once per table row if they are the same for all patient categories.

Alarm Default Settings

Alarm Settings Factory Default H10 / H20 / H40 H30 (deviations from H10/20/40)

Alarm Volume 5

Alarms Off 2 min

Pause Al. 5min Enabled

Pause Al. 10min Enabled

Auto Alarms Off Off

Alarm Off Reminder Off

Visual Latching Red & Yell Red Only

Audible Latching Red & Yell Off

Alarm Reminder On

Reminder Time 3 min

Alarm Sounds Traditional

Red Alarm Interval 10 sec

Yel. Al. Interval 20 sec

Alarm Low 4 2

Red Alarm Volume AlarmVol +2

Yell. Alarm Volume AlarmVol +0

Inop Volume AlarmVol +0

Auto Increase Vol. 2 Steps

Increase Vol Delay 20 sec

Keep Blinking No

Relay 1 Sensitiv. R & Y & C

Relay 2 Sensitiv. Red & Yell

Relay 3 Sensitiv. Red

CyanRelayLatency 5 sec

Yel. Relay Latency 2 sec

Alarm Text Standard

No Centr Mon Min Vol 4

Installation11
- Installation Checklist11
- Unpacking and Checking the Shipment12
- Mounting the Monitor13
- Connecting the Monitor to AC Mains13
- Checking Out The Monitor13
- Loading Paper14
- Operating the Monitor15
- Setting the Date and Time16
- Checking Country-Specific Default Settings16
- Handing Over the Monitor16
Basic Operation19
- Introducing the Monitor19
  - MP5/MP5T Major Parts and Keys22
- Operating and Navigating23
- Operating Modes29
  - Standby Mode29
- Understanding Screens30
  - Switching to a Different Screen30
  - Changing a Screen’s Content30
- Using the XDS Remote Display (not MP5T)31
- Using the Visitor Screen31
- Understanding Profiles32
- Understanding Settings34
  - Changing Measurement Settings35
  - Switching a Measurement On and Off35
- Adjusting a Measurement Wave35
- Freezing Waves36
- Using Labels37
- Entering Measurements Manually39
  - Switching Manually Entered Measurements On and Off39
- Changing Monitor Settings39
- Checking Your Monitor Revision40
- Getting Started40
- Disconnecting from Power42
  - Monitoring After a Power Failure42
- Networked Monitoring42
- Using the MP5 with a Host Monitor43
What’s New?45
- What’s New in Release G.0?45
- What’s New in Release F.0?46
Alarms49
- Visual Alarm Indicators50
- Audible Alarm Indicators51
- Acknowledging Alarms53
  - Acknowledging Disconnect INOPs53
  - Alarm Reminder (ReAlarm)53
- Pausing or Switching Off Alarms54
- Alarm Limits55
- Reviewing Alarms60
  - Alarm Messages Window60
  - Review Alarms Window60
- Latching Alarms62
  - Viewing the Alarm Latching Settings62
  - Alarm Latching Behavior62
- Testing Alarms62
- Alarm Behavior at On/Off63
- Alarm Recordings63
Patient Alarms and INOPs65
- Patient Alarm Messages65
- Technical Alarm Messages (INOPs)71
Managing Patients95
- Admitting a Patient95
  - Patient Category and Paced Status97
  - Admitting a Centrally-Monitored Patient97
- Quick Admitting a Patient97
- Editing Patient Information97
- Discharging a Patient98
  - New Patient Check98
- Transferring Patients99
- Care Groups102
ECG, Arrhythmia, ST and QT Monitoring109
- Skin Preparation for Electrode Placement109
- Connecting ECG Cables109
- Selecting the Primary and Secondary ECG Leads110
- Checking Paced Status110
- Understanding the ECG Display110
- Monitoring Paced Patients111
  - Setting the Paced Status (Pace Pulse Rejection)112
  - Avoiding Pace Pulse Repolarization Tails112
- Changing the Size of the ECG Wave113
  - To Change the Size of an Individual ECG Wave113
  - To Change the Size of all the ECG Waves113
- Changing the Volume of the QRS Tone113
- Changing the ECG Filter Settings114
- Selecting Positions of Va and Vb Chest Leads (for 6- lead placement)114
- Choosing EASI or Standard Lead Placement115
- About ECG Leads115
  - ECG Leads Monitored115
  - Changing Lead Sets115
- ECG Lead Fallback116
- ECG Lead Placements116
  - Standard 3-Lead Placement117
  - Standard 5-Lead Placement117
  - 6-Lead Placement117
  - Chest Electrode Placement118
  - 10-Lead Placement119
  - Conventional 12-Lead ECG119
    - Modified 12-Lead ECG120
  - Choosing Standard or Modified Electrode Placement120
- Capture 12-Lead120
- EASI ECG Lead Placement121
- ECG and Arrhythmia Alarm Overview122
- Using ECG Alarms123
  - Extreme Alarm Limits123
  - ECG Alarms Off Disabled123
  - HR Alarms When Arrhythmia Analysis is Switched Off123
  - Enhanced Asystole Detection123
- ECG Safety Information124
- About Arrhythmia Monitoring125
  - Arrhythmia Options125
  - Where Can I Find More Information?125
- Switching Arrhythmia Analysis On and Off126
- Choosing an ECG Lead for Arrhythmia Monitoring126
  - Aberrantly-Conducted Beats126
  - Atrial Fibrillation Alarm126
  - Intermittent Bundle Branch Block127
- Understanding the Arrhythmia Display127
  - Viewing Arrhythmia Waves128
  - Arrhythmia Beat Labels128
  - Arrhythmia Status Messages129
    - Rhythm Status Messages129
    - Ectopic Status Messages130
- Arrhythmia Relearning130
  - Initiating Arrhythmia Relearning Manually130
  - Automatic Arrhythmia Relearn131
    - Arrhythmia Relearn and Lead Fallback131
- Arrhythmia Alarms131
  - Yellow Arrhythmia Alarms132
  - Arrhythmia Alarms and Latching132
  - Switching Individual Arrhythmia Alarms On and Off132
  - Switching All Yellow Arrhythmia Alarms On or Off132
  - Adjusting the Arrhythmia Alarm Limits132
  - Arrhythmia Alarm Timeout Periods133
    - What is a Timeout Period?133
    - Resetting the Timeout Period133
  - How are Yellow Arrhythmia Alarms Indicated?133
    - Arrhythmia Alarm Chaining134
  - Understanding PVC-Related Alarms135
- About ST Monitoring137
- Switching ST On and Off137
  - Selecting Leads for ST Analysis137
- Understanding the ST Display138
- Updating ST Baseline Snippets139
- Recording ST Segments140
- About the ST Measurement Points140
  - Adjusting ST Measurement Points140
- ST Alarms142
  - Single- or Multi-lead ST Alarming142
  - Changing ST Alarm Limits142
- Viewing ST Maps143
  - Current View143
  - Trend View144
  - Viewing an ST Map145
  - Working in the ST Map Task Window145
- About QT/QTc Interval Monitoring147
  - QT Measurement Algorithm147
    - Where Can I Find More Information?147
  - Indications For Use Of QT Interval Monitoring148
  - Limitations For Use Of QT Interval Monitoring148
  - Selecting The QT Leads148
  - QT View149
- QT Alarms150
  - Switching Individual QTc Alarms On and Off151
  - Changing QTc Alarm Limits151
- Switching QT Monitoring On and Off151
Monitoring Pulse Rate153
- Entering the Setup Pulse Menu153
- System Pulse Source153
- Switching Pulse On and Off154
- Using Pulse Alarms154
Monitoring Respiration Rate (Resp)157
- Lead Placement for Monitoring Resp157
- Understanding the Resp Display158
- Changing Resp Detection Modes158
- Changing the Size of the Respiration Wave159
- Changing the Speed of the Respiration Wave160
- Using Resp Alarms160
- Changing the Apnea Alarm Delay160
- Resp Safety Information160
Monitoring SpO2163
- SpO2 Sensors163
- Applying the Sensor163
- Connecting SpO2 Cables164
- Measuring SpO2164
- SpO2 Signal Quality Indicator (Fast SpO2 only)165
- Assessing a Suspicious SpO2 Reading165
- Changing the Averaging Time166
- Setting the Measurement Mode166
  - Making a Manual Measurement166
- Understanding SpO2 Alarms166
- Pleth Wave167
- Perfusion Numeric168
- Perfusion Change Indicator168
- Setting SpO2/Pleth as Pulse Source168
- Setting Up Tone Modulation168
- Setting the QRS Volume169
Monitoring NBP171
- Introducing the Oscillometric NBP Measurement171
- Preparing to Measure NBP172
  - Correcting the Measurement if Limb is not at Heart Level173
  - Understanding the NBP Numerics173
- Starting and Stopping Measurements174
- Enabling Automatic Mode and Setting Repetition Time175
- Enabling Sequence Mode and Setting Up The Sequence175
- Choosing the NBP Alarm Source176
- Switching Pulse from NBP On/Off176
- Assisting Venous Puncture177
- Calibrating NBP177
Measuring Predictive Temperature179
- Making a Temperature Measurement179
  - Selecting a Temperature Label181
  - Selecting Predictive or Continuous mode181
Monitoring Temperature183
- Making a Temp Measurement183
  - Selecting a Temperature for Monitoring183
  - Extended Temperature Label Set184
- Calculating Temp Difference184
Monitoring Invasive Pressure185
- Setting up the Pressure Measurement185
  - Selecting a Pressure for Monitoring185
  - Extended Pressure Label Set186
- Zeroing the Pressure Transducer186
- Adjusting the Calibration Factor188
- Displaying a Mean Pressure Value Only188
- Changing the Pressure Wave Scale188
- Optimizing the Waveform189
- Using the Wave Cursor189
- Non-Physiological Artifact Suppression189
- Choosing the Pressure Alarm Source189
  - Extreme Alarm Limits190
- Calibrating Reusable Transducer CPJ840J6191
  - Making the Pressure Calibration191
  - Troubleshooting the Pressure Calibration192
- Calculating Cerebral Perfusion192
- Calculating Pulse Pressure Variation192
Monitoring Carbon Dioxide195
- Using the CO2 Measurement196
  - Preparing to Measure Mainstream CO2196
  - Preparing to Measure Sidestream CO2197
    - Using the Sidestream Sensor Holder198
    - Removing Exhaust Gases from the System199
- Measuring Microstream CO2199
- Setting up all CO2 Measurements200
Assigning Two Devices to One Patient205
- How Can You Combine Devices?205
- Functions Available When the Telemetry Data Window is Displayed209
- Functions Available For Devices Connected Via SRR210
  - Temporarily Stopping the Short Range Radio Connection210
  - Setting Up Measurements211
- General Telemetry-related Functions211
  - ECG Source Tracking at the Information Center211
  - Synchronized Settings211
- Use Models With Telemetry212
Enhancing Telemetry Monitoring with the Monitor215
- Monitor and Telemetry Transceiver Requirements215
- Data Sent to the Information Center215
- Changing Assignment to a New Telemetry Transceiver215
Trends217
- Viewing Trends217
- Setting Up Trends220
- Documenting Trends223
- Trends Databases224
  - Aperiodic Trends Database224
  - Trending Multiple-Value Measurements224
- Screen Trends225
High Resolution Trend Waves229
- OxyCRG229
- Printing Hi-Res Trend Wave Reports229
- Hi-Res Trend Wave Recordings230
Event Surveillance231
- Event Episodes231
- Events Pop-Up Keys232
- Event Triggers232
- The Events Database234
- Viewing Events234
- Annotating Events236
- Documenting Events236
ProtocolWatch241
- Severe Sepsis Screening241
Recording247
- Starting and Stopping Recordings247
- Overview of Recording Types248
- All ECG Waves Recordings249
- Creating and Changing Recordings Templates249
- Changing ECG Wave Gain250
- Recording Priorities251
- Sample Recording Strip251
- Reloading Paper253
- Recorder Status Messages253
Printing Patient Reports255
- Starting Report Printouts255
- Stopping Reports Printouts256
- Setting Up Reports256
- Setting Up Individual Print Jobs258
- Checking Printer Settings259
- Printing a Test Report259
- Switching Printers On Or Off for Reports259
- Dashed Lines on Reports259
- Unavailable Printer: Re-routing Reports259
- Checking Report Status and Printing Manually260
  - Printing Manually260
- Printer Status Messages261
- Sample Report Printouts262
Using the Drug Calculator267
- Accessing the Drug Calculator267
- Performing Drug Calculations268
- Charting Infusion Progress270
- Using the Titration Table270
- Documenting Drug Calculations270
Using the Timer271
- Viewing the Timer271
  - Timer Types271
- Timer Setup Pop-up Keys271
- Setting Up Timers272
- Displaying a Timer On The Main Screen273
  - Main Screen Timer Pop-up Keys274
- Displaying A Clock On The Main Screen274
Laboratory Data275
- Viewing Received Data275
Care and Cleaning277
- General Points277
- Cleaning the Monitor278
- Disinfecting the Monitor278
- Sterilizing the Monitor278
- Cleaning, Sterilizing and Disinfecting Monitoring Accessories279
- Cleaning and Disinfecting the Predictive Temperature Accessories279
  - Probes279
  - Probe Holders279
- Cleaning Batteries and the Battery Compartment279
Using Batteries281
- Battery Power Indicators281
- Checking Battery Charge284
- Replacing a Battery284
- Optimizing Battery Performance284
- Battery Safety Information285
Maintenance and Troubleshooting287
- Inspecting the Equipment and Accessories287
- Inspecting the Cables and Cords287
- Maintenance Task and Test Schedule288
- Troubleshooting289
- Disposing of the Monitor289
- Disposing of Empty Calibration Gas Cylinders289
Accessories291
- ECG/Resp Accessories291
  - Recommended Cables291
  - Supported Cables293
- NBP Accessories295
- Invasive Pressure Accessories296
- SpO2 Accessories297
- Temperature Accessories301
- Predictive Temperature Accessories301
- Mainstream CO2 Accessories302
- Sidestream CO2 Accessories302
- Microstream CO2 Accessories302
- Recorder Accessories303
- Cable for Direct Connection of a Telemetry Device304
- Battery Accessories304
Installation and Specifications305
- Intended Use305
- Manufacturer’s Information306
  - Trademark Acknowledgement306
- Symbols306
- Installation Safety Information308
  - Connectors308
    - Left Side of Monitor309
    - Right Side of Monitor310
- Altitude Setting310
- Monitor Safety Specifications310
- EMC And Radio Regulatory Compliance311
- Out-Of-Hospital Transport - Standards Compliance312
  - Physical Specifications313
  - Environmental Specifications314
- Monitor Performance Specifications314
- M4605A Battery Specifications318
- Measurement Specifications319
- Safety and Performance Tests331
Default Settings Appendix337
- Country-Specific Default Settings337
- Alarm and Measurement Default Settings343
- Alarm Default Settings343
- ECG, Arrhythmia, ST and QT Default Settings344
- Pulse Default Settings347
- Respiration Default Settings347
- SpO2 Default Settings348
- NBP Default Settings349
- Temperature Default Settings349
- Predictive Temperature Default Settings350
- Invasive Pressure Default Settings350
- CO2 Default Settings352

Brand	Philips
Model	IntelliVue MP5
Category	Medical Equipment
Language	English

Philips IntelliVue MP5 User Manual

Table of Contents

Other manuals for Philips IntelliVue MP5

Questions and Answers:

Philips IntelliVue MP5 Specifications

Related product manuals
