NBP Default Settings 32 Default Settings Appendix

339

NBP Default Settings

Temperature Default Settings

NBP Settings

Factory defaults H10 / H20 / H40 H30 (deviations from H10/20/40)

Adult Pedi Neo Adult Pedi Neo

Mode Auto Manual

Alarms from Sys.

High Limit 160/90 (110) 120/70 (90) 90/60 (70) 180/90 (110)

Low Limit 90/50 (60) 70/40 (50) 40/20 (24) 70/50 (65)

Alarms On

NBP On

Repetition Time 10 min 3 min

Pulse (NBP) On

Unit mmHg

Done Tone Off On

Start Time Synchronized NotSynchron.

VP Pressure 60 mmHg 40 mmHg 30 mmHg

Reference Auscultatory Invasive

Color Red Magenta

Temp Settings

Factory defaults H10 / H20 / H40 H30 (deviations from H10/20/40)

Adult Pedi Neo Adult Pedi Neo

Low Limit 36 35

High Limit 39

Alarms On

Unit C

Range 35...43

Color Green Light Green
