Monitor Performance Specifications 31 Installation and Specifications
307
Basic Nurse Call
Relay
Connector 3.5 mm phone jack, active closed contact only
Contact
<=100 mA, <=24 V DC
Isolation
1.5 kV
Delay
<(Configured Latency + 0.5 sec)
Wireless Network
Device Interface
(integrated, for
compatible network
options see below)
Signals
RD+/-, TD+/-: IEEE 802.3 10 Base-T, PWR, GND
12.5 V ±20 %, 3.5 W continuous
Short Range Radio
Interface
1
Ty pe Internal SRR interface
Te c hn ol og y
IEEE 802.15.4
Frequency Band
2.4 GHz ISM (2.400 - 2.483 GHz)
Modulation Technique
DSSS (O -QPSK)
Effective radiated
power
max. 0 dBm (1 mW)
1.The short range radio interface is compatible with the following telemetry devices: TRx4841A/TRx4851A IntelliVue
Telemetry System Transceiver.
Display Specifications
All displays Sweep Speeds 6.25, 12.5, 25 and 50 mm/s;
Integrated SVGA
Display
Resolution 800 x 600
Refresh frequency
60 Hz
Useful screen
170.4 x 127.8 mm
Pixel size
0.213 x 0.213 mm
Video Interface SVGA Horizontal Frequency 37.5 kHz
Refresh frequency
60 Hz
Video Signals
0.7 Vpp @ 75 Ohm, HSYNC/VSYNC Signals TTL
Connector
15 pin D-SUB
Compatible Devices
Displays (must be approved
for medical use)
M8031B XGA color 15” LCD touchscreen
M8033C
SXGA color 17” LCD Touchscreen
IntelliVue 802.11 Bedside Adapter (Wireless Network Adapter)
Internal Wireless Adapter Technology IEEE 802.11a/b/g
Frequency Band
2.4 GHz and 5 GHz ISM Band
IntelliVue Instrument Telemetry Wireless Network (USA only)
Internal WMTS Adapter Technology compatible with Philips Cellular Telemetry System
(CTS), cellular infrastructure
Frequency Band
WMTS, 1395-1400 MHz and 1427-1432 MHz
IntelliVue Instrument Telemetry Wireless Network (except USA)
Internal ISM Adapter Technology compatible with Philips Cellular Telemetry System
(CTS), cellular infrastructure
Frequency Band
2.4 GHz ISM
Monitor Interface Specifications
