31 Installation and Specifications Measurement Specifications

312

Respiration Alarm

Specifications Range Adjustment Delay

High Adult/pedi: 10 to 100 rpm

Neo: 30 to 150 rpm

under 20 rpm: 1 rpm steps

over 20 rpm: 5 rpm steps

max. 14 seconds

Low Adult/pedi: 0 to 95 rpm

Neo: 0 to 145 rpm

under 20 rpm: 1 rpm steps

over 20 rpm: 5 rpm steps

for limits from 0 to 20 rpm:

max. 4 seconds

for limits above 20 rpm: max.

14 seconds

Apnea Alarm 10 to 40 seconds 5 second steps
