Technical Alarm Messages (INOPs) 5 Patient Alarms and INOPs
81
tcpO
2
(or tcpCO
2
or tcGas)
UNPLUGGED
Numeric is replaced by -?-
INOP tone.
tcGas The measurement is switched on but the module is unplugged.
The measurement automatically disappears from the display.
Silencing this INOP switches off the measurement.
TELE CONFIG UNSUPP
INOP tone
Monitor Telemetry device not supported (companion mode)
!!/!!!TELE DISCONNECT
INOP tone
Telemetry Telemetry transceiver was disconnected or short range radio
link was lost.
For cable connections; check Telemetry interface, cable
connection and setup.
For short range radio connections: if the telemetry transceiver
has not moved out-of-range, check for interference sources
close to the monitor (bluetooth devices, DECT phones,
cellular phones, microwaves, etc.) If this INOP persists, ask
your service personnel to survey the interference sources.
TELE EQUIP MALF
INOP tone
Monitor The telemetry device has a malfunction. Disconnect and
reconnect the telemetry device. If the INOP reappears, replace
the telemetry device.
TELE INCOMPATIBLE Monitor SRR-enabled telemetry device is not supported by this central
software revision. Please check configuration.
!!/!!! TELE INOP
Severe yellow/red INOP tone.
Telemetry Check for further details at the Information Center or in the
Telemetry Data window on the monitor.
Tele Sync Unsupp.
INOP tone
Telemetry The MMS in use does not support synchronization of ECG
and SpO
2
settings between the monitor and central station
after a telemetry device has been paired. Use an MMS with
revision E.0 or above.
TELE UNSUPPORTED
INOP tone
Monitor This telemetry device is not supported for direct connection to
the monitor.
<Temp> CHK SOURCES
Numeric is replaced by -?-
TEMP
Difference
Not all measurements or values required to perform the
calculation are available. Check measurement sources.
<Temp> CHK UNITS
Numeric is replaced by -?-
TEMP
Difference
The monitor has detected a conflict in the units used for this
calculation. Check the unit settings.
<Temp label> DEACTIVATED
INOP tone
TEMP A Temp measurement label in the measurement device has
been deactivated, either by connecting a Pressure transducer in
the shared Press/Temp socket, or by deactivating the label in
the Measurement Selection window.
The measurement automatically disappears from the display.
To switch the measurement on again, either reconnect a Temp
transducer or reactivate the measurement label in the
Measurement Selection window.
<Temp label> EQUIP MALF
Numeric is replaced by -?-
INOP tone.
TEMP Contact your service personnel.
The temperature hardware is faulty.
<Temp label> NO
TRANSDUCER
Numeric is replaced by -?-
INOP tone.
TEMP Make sure the TEMP probe is connected to the MMS or
module.
If you silence this INOP, the measurement will be switched off.
INOP Message, Indication Source What to do
