LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Interface PCB (A05) Replacement
Section Menu Section Contents Procedures Back Index
194
8
Installing the Interface PCB (A05)
Refer to Interface PCB Replacement Figures (p. 190) and Inside Front Case Diagram (p. 189).
To install the interface PCB into the front case:
NOTE: If a new interface PCB is required, install the Interface PCBA Repair Kit, V1 (MIN 3305431-005) or Interface
PCBA Repair Kit, V2 (MIN 3305431-029).
1. Attach the interface PCB to the bracket with the eight new screws (202253-761); torque to 6.8 in-lb (see Figure 8.10 on p.
190).
2. Install the ground strap (W19) with one new screw (202253-761); torque to 6.8 in-lb (see Figure 8.10 on p. 190).
3. Install the connectors clockwise, as follows (make sure all connector locking tabs are positioned to secure their respective
connectors) (see Figure 8.11 on p. 191 and Figure 8.12 on p. 192):
~ J31 – Install the main keypad interface PCB cable (W13, 3207388-001).
~ J37 – Install the backlight interface PCB cable (W06, 3206992-000).
~ J36 – Install the LCD interface PCB cable (W18, 3206990-001).
~ J32 – Install the printer control keypad interface PCB cable (W12, 3206989-000).
~ J34 – Install the speaker interface PCB wire (W17, 3009726-03).
~ J35 – Install the printer interface cable (W16, 3009724-001).
~ J33 – Install the speed dial cable (W15, 3011128-002).
4. If the interface PCB was replaced, install the system/interface cable to the interface PCB as described in System/Interface PCB
Cable (W04) Replacement (p. 212)
5. Reassemble the case as described in Reassembling the Case (p. 184).
