Planet GSD-1002M User Manual

User’s Manual of GSD-1002M
Buttons
: Click to apply changes.
Figure 4-5-2 Management VLAN State page screenshot
The page includes the following fields:
Object Description
Displa
y the current management VLAN.
 Management VLAN
4.5.4 Create VLAN
Create/delete VLAN on this page. The screens in Figure 4-5-3 & Figure 4-5-4 appear.
Figure 4-5-3 VLAN Setting page screenshot
The page includes the following fields:
Object Description
Indicates the ID of this pa
rticular VLAN.
 VLAN List
Th
is column allowed users to add or delete VLAN s.
 VLAN Action
Indicates the n
ame of this particular VLAN.
 VLAN Name Prefix
Buttons
: Click to apply changes.
102
