User’s Manual of GSD-1002M
Figure 4-11-4 Statics MAC Status page screenshot
The page includes the following fields:
Object Description
Th
is is the number for entries
 No.
The MAC address for the entry
.
 MAC Address
The VLAN ID for the entr
y.
 VLAN
 Delete
Click to delete static MAC status entry.
4.11.3 Dynamic Address Setting
By default, dynamic entries are removed from the MAC table after 300 seconds. The Dynamic Address Setting/Status screens in
Figure 4-11-5 & Figure 4-11-6 appear.
Figure 4-11-5 Dynamic Addresses Setting page screenshot
The page includes the following fields:
Object Description
 Aging Time
The time after which a learned entry is discarded.
(Range: 10-630 seconds; Default: 300 seconds)
Buttons
: Click to apply changes.
269
