Planet GSD-1002M User Manual

User’s Manual of GSD-1002M
Figure 4-8-5 Queue Information page screenshot
The page includes the following fields:
Object Description
Displa
y the current queue method information
 Information Name
Displa
y the current queue vlaue information
 Information Value
4.8.2.4 CoS Mapping
The CoS to Queue and Queue to CoS Mapping screens in Figure 4-8-6 & Figure 4-8-7 appear.
Figure 4-8-6 CoS to Queue and Queue to CoS Mapping page screenshot
The page includes the following fields:
Object Description
Select Queue
value for this drop down list.
 Queue
Select CoS value for this drop dow
n list.
 Class of Service
Buttons
: Click to apply changes.
177
