User’s Manual of GSD-1002M
Buttons
: Click to apply changes.
Figure 4-14-3: RMON Event Status Page Screenshot
The Page includes the following fields:
Object Description
Displa
y the current event index
 Index
Displa
y the current event type
 Event Type
Display t
he current community for SNMP trap
 Community
Displa
y the current event description
 Description
Displa
y the current last sent time
 Last Sent Time
Displa
y the current event owner
 Owner
 Action
Click to delete RMON event entry.
4.14.3 RMON Event Log
This Page provides an overview of RMON Event Log. The RMON Event Log Table screen in Figure 4-14-4 appears.
Figure 4-14-4: RMON Event Log Table Page Screenshot
The Page includes the following fields:
Object Description
 Select Index
Select index for this drop down list
298
