User’s Manual of GSD-1002M
The page includes the following fields:
Object Description
Select port nu
mber for this drop down list.
 Port
Enable or d
isable the port rate policer. The default value is "Disabled".
 State
Configure th
e rate for the port policer. The default value is "unlimited". Valid
values are in the range 0 to 1000000.
 Rate (Kbps)
Buttons
: Click to apply changes.
Figure 4-8-17 Ingress Bandwidth Control Status page screenshot
The page includes the following fields:
Object Description
The s
witch port number of the logical port.
 Port
Displa
y the current ingress rate limit.
 Ingress Rate Limit
(Kbps)
4.8.4.2 Egress Bandwidth Control
This page provides to select the egress bandwidth preamble. The Egress Bandwidth Control Setting and Status screens in
Figure 4-8-18 & Figure 4-8-19 appear.
184
