User’s Manual of GSD-1002M
4.8.4.3 Egress Queue
The Egress Queue Badwidth Control Settings and Status screens in Figure 4-8-20 & Figure 4-8-21 appear.
Figure 4-8-20 Egress Queue BandwidthSettings page screenshot
The page includes the following fields:
Object Description
Select port nu
mber for this drop down list.
ï‚· Port
Select queu
e number for this drop down list.
ï‚· Queue
Enable or d
isable the port rate policer. The default value is "Disabled".
ï‚· State
Configure th
e CIR for the port policer. The default value is "unlimited". Valid
values are in the range 0 to 1000000.
ï‚· CIR (Kbps)
Buttons
: Click to apply changes.
Figure 4-8-21 Egress Queue Status page screenshot
The page includes the following fields:
Object Description
Displa
y the current queue ID
ï‚· Queue ID
ï‚· Rate Limit (Kbps)
Display the current rate limit.
186
