User’s Manual of GSD-1002M
4.8.2 General
4.8.2.1 QoS Properties
The QoS Global Setting and Information screen in Figure 4-8-1 & Figure 4-8-2 appear.
Figure 4-8-1 QoS Global Setting page screenshot
The page includes the following fields:
Object Description
Enable or d
isable QoS mode
 QoS Mode
Buttons
: Click to apply changes.
Figure 4-8-2 QoS Information page screenshot
The page includes the following fields:
Object Description
Displa
y the current QoS mode.
 QoS Mode
4.8.2.2 QoS Port Settings
The QoS Port Settings and Status screen in Figure 4-8-2 & Figure 4-8-3 appear.
