User’s Manual of GSD-1002M
The page includes the following fields:
Object Description
The s
witch port number of the logical port.
 Port
Displa
y the current forwarded
 Forwarded
Source MAC Failures
Display the current source MAC failures
Displa
y the current source MAC failures
 Dest MAC Failures
 SIP Validation Failures
Display the current SIP Validation failures
 DIP Validation Failures
Display the current DIP Validation failures
Displa
y the current IP-MAC mismatch dailures
 IP-MAC Mismatch
Failures
Buttons
: Click to clear the statistics.
: Click to refresh the statistics.
4.9.8.5 Rate Limit
The ARP Rate Limit Setting and Config screens in Figure 4-9-57 & Figure 4-9-58 appear.
Figure 4-9-57 ARP Rate Limit Setting page screenshot
The page includes the following fields:
Object Description
Select port for this drop dow
n list.
 Port
Set default or us
er-define.
 State
 Rate Limit (pps)
Configure the rate limit for the port policer. The default value is "unlimited".
235
