4.5.12 GVRP VLAN
The GVRP VLAN Database screen in Figure 4-5-17 appears.
Figure 4-5-17 GVRP VLAN Database Status page screenshot
The page includes the following fields:
Object Description
Displa
y the current VLAN ID.
 VLAN ID
Displa
y the current member ports.
 Member Ports
Displa
y the current dynamic ports.
 Dynamic Ports
Displa
y the current VLAN type.
 VLAN Type
4.5.13 GVRP Statistics
The GVRP Port Statistics and Error Statistics screens in Figure 4-5-18 & Figure 4-5-19 appear.
Figure 4-5-18 GVRP Port Statistics page screenshot
The page includes the following fields:
Object Description
The s
witch port number of the logical port.
 Port
 Join Empty (Rx/Tx)
Display the current join empty (TX/RX) packets.
