User’s Manual of GSD-1002M
4.2.7.7 SNMPv1, 2 Notification Recipients
Configure SNMPv1 and 2 notification recipients on this page. The SNMPv1, 2 Notification Recipients screens in Figure 4-2-31 &
Figure 4-2-32 appear.
Figure 4-2-31 SNMPv1, 2 Notification Recipients page screenshot
The page includes the following fields:
Object Description
Server Address
Indicates the SNMP trap destination address. It allow a valid IP address in dotted
decimal notation ('x.y.z.w'). And it also allow a valid hostname. A valid hostname
is a string drawn from the alphabet (A-Za-z), digits (0-9), dot (.), dash (-). Spaces
are not allowed, the first character must be an alpha character, and the first and
last characters must not be a dot or a dash.
Indicates the SNMP trap destination IPv6 address. IPv6 address is in 128-bit
records represented as eight fields of up to four hexadecimal digits with a colon
separating each field (:). For example, 'fe80::215:c5ff:fe03:4dc7'. The symbol '::'
is a special syntax that can be used as a shorthand way of representing multiple
16-bit groups of contiguous zeros; but it can appear only once. It can also
represent a legally valid IPv4 address. For example, '::192.1.2.34'.
SNMP Version
Indicates the SNMP trap supported version. Possible versions are:
SNMP v1: Set SNMP trap supported version 1.
SNMP v2c: Set SNMP trap supported version 2c.
Set the notify
type in traps or informs.
Notify Type
Indicates the communit
y access string when send SNMP trap packet.
Community Name
Indicates the SN
MP trap destination port. SNMP Agent will send SNMP message
via this port, the port range is 1~65535.
UDP Port
Indicates the SNMP trap inform timeout. The allowed range is 1 to 300.
Time Out
Indicates the SNMP trap inform retry times. The allowed range is 1 to 255.
Retries
Buttons
: Click to add a new SNMPv1, 2 host entry.
61
