User’s Manual of GSD-1002M
The page includes the following fields:
Object Description
Set the QoS mode
 Trust Mode
Buttons
: Click to apply changes.
Figure 4-8-13 QoS Information page screenshot
The page includes the following fields:
Object Description
Displa
y the current QoS mode
 Trust Mode
4.8.3.2 Port Settings
The QoS Port Setting and Status screen in Figure 4-8-14 & Figure 4-8-15 appear.
Figure 4-8-14 Basic Mode Global Settings page screenshot
The page includes the following fields:
Object Description
Select port nu
mber for this drop down list.
 Port
 Trust Mode
Enable or disable the trust mode.
182
