User’s Manual of GSD-1002M
Figure 4-9-21 Telnet Information page screenshot
The page includes the following fields:
Object Description
Displa
y the current telent service.
 Telnet Service
 Login Authentication List
Display the current login authentication list
 Enable Authentication List
Display the current enable authentication list
Displa
y the current session timeout.
 Session Timeout
Displa
y the current password retry count
 Password Retry Count
Displa
y the current silent time
 Silent Time
Displa
y the current telnet session count.
 Current Telent Session
Count
4.9.5.2 SSH
Configure SSH on this Page. This Page shows the Port Security status. Port Security is a module with no direct configuration.
Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port,
the port is set-up for software-based learning. In this mode, frames from unknown MAC addresses are passed on to the port
security module, which in turn asks all user modules whether to allow this new MAC address to forward or block it. For a MAC
address to be set in the forwarding state, all enabled user modules must unanimously agree on allowing the MAC address to
forward. If only one chooses to block it, it will be blocked until that user module decides otherwise.
The SSH Settings and Information screens in Figure 4-9-23 & Figure 4-9-24 appear.
211
