User’s Manual of GSD-1002M
The page includes the following fields:
Object Description
Th
is is the logical port number for this row.
 Port
 Description
Click
to indicate the port name.
Displa
y the current port state.
 Enable State
Displa
y the current link status.
 Link Status
Displa
y the current speed status of the port.
 Speed
Displa
y the current duplex status of the port.
 Duplex
Displa
y the current flow control configuration of the port.
 Flow Control
Configuration
Displa
y the current flow control status of the port.
 Flow Control Status
4.3.2 Port Counters
This page provides an overview of traffic and trunk statistics for all switch ports. The Port Statistics screens in Figure 4-3-3,
Figure 4-3-4, Figure 4-3-5 & Figure 4-3-6 appear.
Figure 4-3-3 Port MIB Counters page screenshot
The page includes the following fields:
Object Description
Select port nu
mber for this drop down list.
 Port
 Mode
Select port counters mode.
Option:
 All
 Interface
 Ether-link
 RMON
69
