User’s Manual of GSD-1002M
4.2.7.10 SNMP Remote Engine ID
Configure SNMPv3 remote Engine ID on this page. The SNMPv3 Remote Engine ID Setting screens in Figure 4-2-37 & Figure
4-2-38 appear.
Figure 4-2-37 SNMPv3 Remote Engine ID Setting page screenshot
The page includes the following fields:
Object Description
ï‚· Remote IP Address
Indicates the SNMP remote engine ID address. It allow a valid IP address in
dotted decimal notation ('x.y.z.w'). And it also allow a valid hostname. A valid
hostname is a string drawn from the alphabet (A-Za-z), digits (0-9), dot (.), dash
(-). Spaces are not allowed, the first character must be an alpha character, and
the first and last characters must not be a dot or a dash.
Indicates the SNMP trap destination IPv6 address. IPv6 address is in 128-bit
records represented as eight fields of up to four hexadecimal digits with a colon
separating each field (:). For example, 'fe80::215:c5ff:fe03:4dc7'. The symbol '::'
is a special syntax that can be used as a shorthand way of representing multiple
16-bit groups of contiguous zeros; but it can appear only once. It can also
represent a legally valid IPv4 address. For example, '::192.1.2.34'.
An octet string identif
ying the engine ID that this entry should belong to.
ï‚· Engine ID
Buttons
: Click to apply changes.
Figure 4-2-38 SNMPv3 Remote Engine ID Status page screenshot
The page incl
udes the following fields:
65
