User’s Manual of GSD-1002M
4.3.7 Port Error Disabled
This page provides disable that transitions a port into error disable and the recovery options. The ports were disabled by some
protocols such as BPDU Guard, Loopback and UDLD. The Port Error Disable screen in Figure 4-3-15 appears.
Figure 4-3-15 Port Error Disable page screenshot
The displayed counters are:
Object Description
Display
the port for error disable.
 Port Name
 Error Disable Reason
Display the error disabled reason of the port.
Display
the time left.
 Time Left (Seconds)
4.3.8 Protected Ports
Overview
When a switch port is configured to be a member of protected group (also called Private VLAN), communication between
protected ports within that group can be prevented. Two application examples are provided in this section:
 Customers connected to an ISP can be members of the protected group, but they are not allowed to communicate with
each other within that VLAN.
 Servers in a farm of web servers in a Demilitarized Zone (DMZ) are allowed to communicate with the outside world and
with database servers on the inside segment, but are not allowed to communicate with each other
80
