User’s Manual of GSD-1002M
Indicates the in
dex of the log entry.
 Index
Indicates Even
t log time.
 Log Time
Indicates the Event descri
ption.
 Description
4.14.4 RMON Alarm
Configure RMON Alarm table on this Page. The RMON Alarm screens in Figure 4-14-5 & Figure 4-14-6 appear.
Figure 4-14-5: RMON Alarm Table Page Screenshot
The Page includes the following fields:
Object Description
Select inde
x for this drop down list to create the new index or modify the index
 Select Index
Indicates the in
dex of the alarm entry.
 Index
Select port for this drop dow
n list
 Sample Port
 Sample Variable
Indicates the particular variable to be sampled, the possible variables are:
 DropEvents: The total number of events in which packets were dropped due
to lack of resources.
 Octets: The number of received and transmitted (good and bad) bytes.
299
