User’s Manual of GSD-1002M
Includes FCS, but excludes framing bits.
 Pkts: The total number of frames (bad, broadcast and multicast) received
and transmitted.
 BroadcastPkts: The total number of good frames received that were
directed to the broadcast address. Note that this does not include multicast
packets.
 MulticastPkts: The total number of good frames received that were directed
to this multicast address.
 CRCAlignErrors: The number of CRC/alignment errors (FCS or alignment
errors).
 UnderSizePkts: The total number of frames received that were less than 64
octets long(excluding framing bits, but including FCS octets) and were
otherwise well formed.
 OverSizePkts: The total number of frames received that were longer than
1518 octets(excluding framing bits, but including FCS octets) and were
otherwise well formed.
 Fragments: The total number of frames received that were less than 64
octets in length (excluding framing bits, but including FCS octets) and had
either an FCS or alignment error.
 Jabbers: The total number of frames received that were longer than 1518
octets(excluding framing bits, but including FCS octets), and had either an
FCS or alignment error.
 Collisions: The best estimate of the total number of collisions on this
Ethernet segment.
 Pkts64Octets: The total number of frames (including bad packets) received
andtransmitted that were 64 octets in length (excluding framing bits but
including FCS octets).
 Pkts64to172Octets: The total number of frames (including bad packets)
received andtransmitted where the number of octets fall within the specified
range (excluding framing bits but including FCS octets).
 Pkts158to255Octets: The total number of frames (including bad packets)
received andtransmitted where the number of octets fall within the specified
range (excluding framing bits but including FCS octets).
 Pkts256to511Octets: The total number of frames (including bad packets)
received andtransmitted where the number of octets fall within the specified
range (excluding framing bits but including FCS octets).
 Pkts512to1023Octets: The total number of frames (including bad packets)
received andtransmitted where the number of octets fall within the specified
range (excluding framing bits but including FCS octets).
 Pkts1024to1518Octets: The total number of frames (including bad packets)
