User’s Manual of GSD-1002M
Figure 4-9-8 Guest VLAN Status page screenshot
The page includes the following fields:
Object Description
The s
witch port number of the logical port.
 Port Name
Displa
y the current state.
 Enable State
Displa
y the current guest VLAN.
 In Guest VLAN
4.9.1.5 Authenticed Host
The Authenticated Host Table screen in Figure 4-9-9 appears.
Figure 4-9-9 Authenticed Host Table page screenshot
The page includes the following fields:
Object Description
Displa
y the current user name.
 User Name
Displa
y the current port number.
 Port
Displa
y the current session time.
 Session Time
 Authentication Method
Display the current authentication method.
Displa
y the current MAC address.
 MAC Address
201
