User’s Manual of GSD-1002M
The p
ayload size of the ICMP packet. Values range from 8bytes to 5120bytes.
Size (in bytes)
Displa
y the current ping result.
Ping Results
Buttons
: Click to transmit ICMP packets.
Be sure the target IP Address is within the same network subnet of the switch, or you have to set up
the correct gateway IP address.
4.13.4 IPv6 Ping Test
This page allows you to issue ICMPv6 PING packets to troubleshoot IPv6 connectivity issues.
After you press “Apply”, 5 ICMPv6 packets are transmitted, and the sequence number and roundtrip time are displayed upon
reception of a reply. The page refreshes automatically until responses to all packets are received, or until a timeout occurs. The
ICMPv6 Ping screen in Figure 4-13-4 appears.
Figure 4-13-4 ICMPv6 Ping page screenshot
The page includes the following fields:
292
