User’s Manual of GSD-1002M

4.7.4.6 MLD Forward All

This page provides MLD Forward All. The Forward All screen in Figure 4-7-32 appears.

Figure 4-7-32 Forward All Setting page screenshot

The page includes the following fields:

Object Description

Select VLAN ID

for this drop down list to assign MLD membership.

 VLAN ID

The s

witch port number of the logical port.

 Port

Select MLD membership for each interface:

Forbidden:

Interface is forbidden from automatically joining the MLD via MVR.

None:

Interface is not a member of the VLAN. Packets associated with

this VLAN will not be transmitted by the interface.

 Membership

Static:

Interface is a member of the MLD.

Buttons

: Click to apply changes.

4.7.5 MLD Snooping Statics

This page provides MLD Snooping Statics. The MLD Snooping Statics screen in Figure 4-7-33 appears.

164
