User’s Manual of GSD-1002M
2.1.2 LED Indications
ower, and help monitor and troubleshoot
2 shows the LED indications of these Managed Switches.
The front panel LEDs indicate instant status of port links, data activity and system p
when needed. Figure 2-
LED Indication
Figure 2-2 GSD-1002M LED panel
â– System
LED Color Function
PWR Green
Lights to indicate that the Switch has power.
â– 10/1 as rfaces 00/1000B e-T inte
LED Color Function
Lights:
To indicate the link through that port is successfully established.
LNK/ACT Green
s:
rt.
Blink
To indicate that the switch is actively sending or receiving data over that po
Lights: To indicate that the port is operating at 1000Mbps.
1000 Orange
Off: If LNK/ACT LED light-> indicates that the port is operating at 10/100Mbps
If LNK/ACT LED Off -> indicates that the port is link down
â– 100 Base- nterfaces / 1000 X SFP i
LED Color Function
Lights:
To indicate the link through that port is successfully established.
LNK/ACT Green
s:
port.
Blink
To indicate that the switch is actively sending or receiving data over that
Lights: To indicate that the port is operating at 1000Mbps.
1000 Orange
Off: If LNK/ACT LED light-> indicates that the port is operating at 100Mbps
If LNK/ACT LED Off -> indicates that the port is link down
20
