User’s Manual of GSD-1002M
4.7.4 MLD Snooping
4.7.4.1 MLD Setting
This page provides MLD Snooping related configuration.
Most of the settings are global, whereas the Router Port configuration is related to the current unit, as reflected by the page
header. The MLD Snooping Setting, Information and Table screens in Figure 4-7-21, Figure 4-7-22 & Figure 4-7-23 appear.
Figure 4-7-21 MLD Snooping page screenshot
The page includes the following fields:
Object Description
Enable or d
isable the MLD snooping. The default value is "Disabled".
 MLD Snooping Status
 MLD Snooping Version
Sets the MLD Snooping operation version. Possible versions are:
v1: Set MLD Snooping supported MLD version 1.
v2: Set MLD Snooping supported MLD version 2.
Limits
the membership report traffic sent to multicast-capable routers. When you
disable report suppression, all MLD reports are sent as is to multicast-capable
routers. The default is enabled.
 MLD Snooping Report
Suppression
Buttons
: Click to apply changes.
Figure 4-7-22 MLD Snooping information page screenshot
The page includes the following fields:
158
