Planet GSD-1002M - Product Specifications

User’s Manual of GSD-1002M
1.5 Product Specifications
Product GSD-1002M
Hardware Specifications
Copper Ports 8 x 10/100/1000Base-T RJ45 Auto-MDI/MDI-X ports
SFP/mini-GBIC Slots
2 100/1000Base-X SFP interfaces
Supports 100/1000Mbps dual mode and DDM
Switch Architecture Store-and-Forward
Switch Fabric 20Gbps / non-blocking
Switch Throughput@64Bytes 14.8Mpps@64Bytes
Address Table 8K entries
Share Data Buffer 4.1 megabits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame
10K bytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory Default
LED
System:
Power (Green)
10/100/1000T RJ45 Interfaces (Port 1 to Port 8):
1000Mbps (Orange), LNK/ACT (Green)
100/1000Mbps SFP Interfaces (Port 9 to Port 10):
1000Mbps (Orange), LNK/ACT (Green)
Thermal Fan Fan-less design (No Fan)
Power Requirements
 IEEE802.3af / at PoE 48V ~ 56V DC in-line power
 12V DC power adapter
ESD Protection 6KV DC
Power Consumption / Dissipation 10.9 watts / 37.2 BTU
Dimensions (W x D x H) 191 x 86 x 26 mm
Weight 396g
Enclosure Metal
Layer 2 Functions
Port Mirroring
TX / RX / Both
Many-to-1 monitor
VLAN
802.1Q Tagged-based VLAN
Up to 256 VLAN groups, out of 4094 VLAN IDs
802.1ad Q-in-Q tunneling
Voice VLAN
Protocol VLAN
Private VLAN (Protected port)
GVRP
Link Aggregation
IEEE 802.3ad LACP and static trunk
Supports 8 groups of 8-port trunk
16
