User’s Manual of GSD-1002M
The page includes the following fields:
Object Description
Displa
y the current SNMP view name
 View Name
Displa
y the current SNMP subtree OID
 Subtree OID
Displa
y the current SNMP OID mask
 OID Mask
Displa
y the current SNMP view type
 View Type
 Action
: Delete the view table entry.
4.2.7.4 SNMP Access Group
Configure SNMPv3 access group on this page. The entry index keys are Group Name, Security Model and Security Level.
The SNMPv3 Access Group Setting screens in Figure 4-
2-25 & Figure 4-2-26 appear.
Figure 4-2-25 SNMPv3 Access Group Setting page screenshot
The p
age includes the following fields:
Object Description
 Group Name
A string identifying the group name that this entry should belong to.
The allowed string length is 1 to 16.
 Security Model
Indicates the security model that this entry should belong to.
Possible security models are:
 v1: Reserved for SNMPv1.
 v2c: Reserved for SNMPv2c.
 V3: Reserved for SNMPv3 or User-based Security Model (USM)
 Security Level
Indicates the security model that this entry should belong to.
Possible security models are:
 Noauth: None authentication and none privacy security levels are
assigned to the group.
 auth: Authentication and none privacy.
 priv: Authentication and privacy.
56
