Planet GSD-1002M - IP Precedence Mapping

User’s Manual of GSD-1002M
The page includes the following fields:
Object Description
Displa
y the current CoS value
 DSCP
Displa
y the current mapping to queue
 Mapping to Queue
Displa
y the current queue value
 Queue
Displa
y the current mapping to DSCP
 Mapping to DSCP
4.8.2.6 IP Precedence Mapping
The IP Precedence to Queue and Queue to IP Precedence Mapping screens in Figure 4-8-10 & Figure 4-8-11 appear.
Figure 4-8-10 IP Precedence to Queue and Queue to IP Precedence Mapping page screenshot
The page includes the following fields:
Object Description
Select Queue
value for this drop down list.
 Queue
Select IP Prec
edence value for this drop down list.
 IP Precedence
Buttons
: Click to apply changes.
