User’s Manual of GSD-1002M
User-defin
ed text that identifies the VoIP devices.
ï‚· Description
Buttons
: Click to add voice VLAN OUI setting.
Figure 4-8-25 Voice VLAN OUI Group page screenshot
The page includes the following fields:
Object Description
Displa
y the current OUI address
ï‚· OUI Address
Displa
y the current description
ï‚· Description
ï‚· Modify
Click
to edit voice VLAN OUI group parameter.
Click
to delete voice VLAN OUI group parameter.
4.8.5.4 Telephony OUI Port Setting
The Voice VLAN feature enables voice traffic forwarding on the Voice VLAN, then the switch can classify and schedule network
traffic. It is recommended that there be two VLANs on a port - one for voice, one for data. Before connecting the IP device to the
switch, the IP phone should configure the voice VLAN ID correctly. It should be configured through its own GUI. The Telephony
OUI MAC Setting screens in Figure 4-8-26 & Figure 4-8-27 appear.
190
