User’s Manual of GSD-1002M
The page includes the following fields:
Object Description
The s
witch port number of the logical port.
 Port
Displa
y the current coordinate.
 Coordinate
Displa
y the current civic address.
 Civic Address
Displa
y the current ESC ELIN.
 ESC ELIN
4.12.8 LLDP Overloading
The LLDP Port Overloading screen in Figure 4-12-16 appears.
Figure 4-12-16 LLDP Port Overloading Table page screenshot
The page includes the following fields:
Object Description
The s
witch port number of the logical port.
 Interface
To
tal number of bytes of LLDP information that is normally sent in a packet.
 Toltal (Bytes)
 Left to Send (Bytes)
Total number of available bytes that can also send LLDP information in a packet.
286
