User’s Manual of GSD-1002M
Displa
y the current inventory
 Inventory
The MED Location Configuration and LLDP MED Port Location Table screens in Figure 4-12-14 & Figure 4-12-15 appear.
Figure 4-12-14 Port LLDP MED Configuraiton page screenshot
The page includes the following fields:
Object Description
Select port for this drop dow
n list.
 Port
 Location Coordinate
A string identifying the Location Coordinate that this entry should belong to.
A string identif
ying the Location Civic Address that this entry should belong to.
 Location Civic
Address
A string identif
ying the Location ESC ELIN that this entry should belong to.
 Location ESC ELIN
Buttons
: Click to apply changes.
Figure 4-12-15 LLDP MED Port Location Table page screenshot
285
