User’s Manual of GSD-1002M
4.14.2 RMON Event
Configure RMON Event table on this Page. The RMON Event screens in Figure 4-14-2 & Figure 4-14-3 appear.
Figure 4-14-2: RMON Event Configuration Page Screenshot
The Page includes the following fields:
Object Description
Select inde
x for this drop down list to create new index or modify index.
 Select Index
Indicates the in
dex of the entry. The range is from 1 to 65535.
 Index
 Type
Indicates the notification of the event, the possible types are:
 none: The total number of octets received on the interface, including framing
characters.
 log: The number of uni-cast packets delivered to a higher-layer protocol.
 SNMP-Trap: The number of broad-cast and multi-cast packets delivered to a
higher-layer protocol.
 Log and Trap: The number of inbound packets that are discarded even the
packets are normal.
Specif
y the community when trap is sent, the string length is from 0 to 127,
default is "public".
 Community
Indicates the o
wner of this event, the string length is from 0 to 127, default is a
null string.
 Owner
Indicates de
scription of this event, the string length is from 0 to 127, default is a
null string.
 Description
