User’s Manual of GSD-1002M
Figure 4-8-7 CoS Mapping page screenshot
The page includes the following fields:
Object Description
Displa
y the current CoS value
 CoS
Displa
y the current mapping to queue
 Mapping to Queue
Displa
y the current queue value
 Queue
Displa
y the current mapping to CoS
 Mapping to CoS
4.8.2.5 DSCP Mapping
The DSCP to Queue and Queue to DSCP Mapping screens in Figure 4-8-8 & Figure 4-8-9 appear.
