Gives the status of the
TLVs.
 Status
Displa
ys if the mandatory group of TLVs were transmitted or overloaded.
 Mandatory TLVs
Displa
ys if the capabilities packets were transmitted or overloaded.
 MED Capabilites
Displa
ys if the location packets were transmitted or overloaded.
 MED Location
 MED Network Policy
Displays if the network policies packets were transmitted or overloaded.
 MED Extended Power
via MDI
Displays if the extended power via MDI packets were transmitted or overloaded.
Displa
ys if the 802.3 TLVs were transmitted or overloaded.
 802.3 TLVs
If the LLDP MED ext
ended power via MDI packets were sent, or if they were
overloaded.
 Optional TLVs
Displa
ys if the mandatory group of TLVs was transmitted or overloaded.
 MED Inventory
Displa
ys if the 802.1 TLVs were transmitted or overloaded.
 802.1 TLVs
4.12.9 LLDP Statistics
Use the LLDP Device Statistics screen to general statistics for LLDP-capable devices attached to the switch, and for LLDP
protocol messages transmitted or received on all local interfaces. The LLDP Global and Port Statistics screens in Figure 4-12-17
& Figure 4-12-18 appear.
Figure 4-12-17 LLDP Global Statistics page screenshot
The page includes the following fields:
Object Description
Show
s the number of new entries added since switch reboot.
 Insertions
Show
s the number of new entries deleted since switch reboot.
 Deletions
Show
s the number of LLDP frames dropped due to that the entry table was full.
 Drops
Show
s the number of entries deleted due to Time-To-Live expiring.
 Age Outs
