User’s Manual of GSD-1002M
4.15.2 Reboot Switch
The Reboot page enables the device to be rebooted from a remote location. Once the Reboot button is pressed, user has to
re-login the WEB interface about 60 seconds later. The Reboot Switch screen in Figure 4-15-2 appears and click to reboot the
system.
Figure 4-15-2 Reboot Switch page screenshot
4.15.3 Backup Manager
This function allows backup of the current image or configuration of the Managed Switch to the local management station. The
Backup Manager screen in Figure 4-15-3 appears.
Figure 4-15-3 Backup Manager page screenshot
The page includes the following fields:
Object Description
Select backup
method for this drop down list.
 Backup Method
Fill in yo
ur TFTP server IP address.
 Server IP
Select backup
type.
 Backup Type
Select active or
backup image.
 Image
Buttons
: Click to backup image, configuration or log.
305
